Goods Lift

Goods Only

Reliable and Efficient Vertical Transport for Materials and Goods
The Goods Only Lift by OND Lift Germany is designed exclusively for the safe and efficient vertical transportation of goods and materials — without carrying personnel.
Built for durability, precision, and safety, it provides an ideal solution for industrial facilities, warehouses, logistics centers, and production plants where reliability and load capacity are essential.

Holen Sie sich jetzt ein Angebot
Goods Only
Single Column Goods Lift Single Column Goods Lift

Single Column Goods Lift

Double Column Goods Lift Double Column Goods Lift

Double Column Goods Lift

Four Column Goods Lift Four Column Goods Lift

Four Column Goods Lift

Goods Only Lift | OND Lift Germany

Reliable and Efficient Vertical Transport for Materials and Goods

The Goods Only Lift by OND Lift Germany is designed exclusively for the safe and efficient vertical transportation of goods and materials — without carrying personnel.
Built for durability, precision, and safety, it provides an ideal solution for industrial facilities, warehouses, logistics centers, and production plants where reliability and load capacity are essential.

Thanks to its modular design, the system can be adapted to specific load capacities, platform sizes, and travel heights, ensuring optimal performance in every operational environment.

⚙️ Technical Features and Configurations

  • Load capacity: 500 kg to 50,000 kg (custom options available)
    • Lift height: Up to 20 meters
    • Platform dimensions: Custom-built for pallets, containers, or special loads
    • Drive system: Electro-hydraulic with smooth start/stop control
    • Construction: Powder-coated steel frame with corrosion protection
    • Installation types: Free-standing, shaft-guided, or integrated into building structures
    • Versions:
    – Single Column Lift – compact solution for small loads and limited spaces
    – Double Column Lift – medium-duty model for larger platforms and higher capacity
    – Four Column Lift – heavy-duty lift for oversized or high-weight loads

🔒 Safety and Control Systems

As a goods-only lift, the system is built to meet the highest machine safety standards for unmanned operation:

  • CE-certified and compliant with Machine Directive 2006/42/EC
    • Mechanical safety catches for fall prevention
    • Overload and pressure relief valves integrated into the hydraulic circuit
    • Door interlocks on all landings to prevent unsafe access
    • Photoelectric light barriers or sensors for obstacle detection
    • Emergency stop and key switch controls for authorized use
    • Safety spacing between all moving components
    • Maintenance support bars for safe servicing

🧭 Typical Applications

The Goods Only Lift is the ideal material-handling solution wherever goods need to be transferred vertically — safely and efficiently:

  • Production and assembly areas – feeding materials between floors
    • Warehouses and logistics centers – pallet movement across multiple levels
    • Retail and commercial facilities – transferring stock between store and storage areas
    • Industrial buildings – connecting production zones and technical floors
    • Hotels and restaurants – serving as compact service lifts for kitchen or supply use

🏗️ Available Configurations

Version Description
Single Column Goods Lift Compact and space-saving – ideal for light loads and limited installation space
Double Column Goods Lift The all-rounder – larger platform and higher capacity for medium loads
Four Column Goods Lift Maximum stability and strength – designed for heavy and oversized materials

🌟 Your Advantages with OND Lift Germany

Advantage Description
Safe & Reliable Fully compliant with Machine Directive 2006/42/EC and CE-certified
Flexible & Scalable Adaptable for various industries and building types
High Load Capacity Handles loads up to 50,000 kg and beyond
Customizable Platform, height, and control options tailored to your project
Low Maintenance Durable components and minimal service requirements
Energy-Efficient Optimized hydraulics for sustainable operation

🚀 Smart Vertical Transport for Modern Industries

The Goods Only Lift by OND Lift Germany delivers maximum efficiency, reliability, and safety for every material-handling application.
With its robust construction, modular configurations, and CE-certified safety systems, it represents a future-ready lifting solution for industrial and logistics environments — Made in Germany.

OND Lift Germany – Intelligent Vertical Solutions for Safe Material Movement.

Efficiency, safety, and quality — built into every lift.
