Goods Lift

Goods Lifts | OND Lift Germany

Vertical Handling Solutions for Every Requirement – Safe, Modular, and Future-Ready

The Goods Lifts by OND Lift Germany represent German engineering excellence in vertical material transport.
Designed and manufactured in accordance with the European Machine Directive 2006/42/EC, these lifting systems ensure maximum safety, precision, and efficiency for industrial, logistics, and commercial environments.

OND Lift Germany offers three main product types to meet diverse operational needs:
1️⃣ Goods Only Lift – for material transport only
2️⃣ Attended On Board Lift – with operator on platform
3️⃣ Automated Goods Lift – integrated with FTS and AMR systems

Each model is available in Single Column, Double Column, or Four Column versions, providing flexible configurations for different capacities, platform sizes, and installation spaces.

⚙️ Structural Versions

Single Column Goods Lift

The Single Column model is ideal for light to medium loads and installations with limited floor space.
Its compact design makes it perfect for workshops, small warehouses, and intermediate levels, while maintaining stable lifting performance.

Technical Highlights:
• Capacity up to 1,000 kg
• Platform size up to approx. 1,500 × 1,500 mm
• Lift height up to 6 meters
• Compact and space-saving configuration

Double Column Goods Lift

The Double Column version is the most versatile configuration within the OND Lift Germany portfolio.
It provides higher load capacity and larger platform dimensions, while maintaining a compact footprint.
Ideal for industrial plants, production halls, and logistics centers.

Technical Highlights:
• Capacity up to 5,000 kg
• Platform size up to 3,000 × 3,000 mm
• Lift height up to 12 meters
• Available as through-loading or single-entry model

Four Column Goods Lift

The Four Column system is the heavy-duty solution designed for large platforms and extreme loads.
With maximum stability and precision even under full load, it is perfect for factories, depots, and vehicle or container transport applications.

Technical Highlights:
• Capacity up to 20,000 kg
• Platform size up to 6,000 × 5,000 mm
• Lift height up to 20 meters
• Heavy-duty steel frame for maximum rigidity

🧭 Product Categories Overview

🚧 1. Goods Only Lift

The Goods Only Lift is designed exclusively for transporting goods and materials, not for passengers.
Built for industrial, warehouse, and logistics environments, it ensures safe, efficient, and cost-effective material handling between levels.

Key Features:
• CE-certified and compliant with Machine Directive 2006/42/EC
• Overload protection and mechanical safety locks
• Hydraulic system with controlled lifting speed
• Safe, quiet, and low-maintenance operation
• Ideal for factories, warehouses, and retail storage areas

👷 2. Attended On Board Lift

The Attended On Board Lift is designed for situations where the operator must travel with the goods.
It combines robust industrial performance with enhanced safety systems to allow safe personnel presence on the platform.

Safety & Control Features:
• Hold-to-run control and emergency stop
• Intercom communication system
• Visual and acoustic warning lights (green/red indicators)
• Light barriers and safety gates at all entrances
• Automatic emergency lowering and overload protection
• Fully CE-certified under Machine Directive 2006/42/EC

Applications:
– Service and maintenance operations
– Vehicle lifts (driver-on-board configurations)
– Production and logistics with supervised handling
– Multi-level material transfer zones

🤖 3. Automated Goods Lift – FTS & AMR Integrated

The Automated Goods Lift is engineered for Industry 4.0 environments, seamlessly integrating with FTS (Automated Guided Vehicles) and AMR (Autonomous Mobile Robots).
It enables fully automated, data-driven material flow between floors and process zones.

Technological Features:
• Intelligent communication via CAN-Bus, Modbus, or customer-specific interfaces
• Automatic lift call and docking systems for FTS/AMR vehicles
• Smart safety zoning and optical sensors
• Energy-efficient electric drive systems
• Ready for Smart Factory integration (ERP/MES compatible)

Benefits:
✅ Reduces manual handling and downtime
✅ Increases process automation and data integration
✅ Compatible with warehouse robotics and smart logistics systems
✅ Ideal for high-performance industrial environments

🌟 Why Choose OND Lift Germany Goods Lifts?

🚀 Reliable Vertical Logistics for Modern Industry

The Goods Lifts by OND Lift Germany combine traditional strength with advanced automation.
Whether you need a standard material lift, a supervised attended version, or a fully automated solution integrated into your robotic fleet,
OND Lift Germany delivers custom-engineered, CE-compliant, and future-ready lifting technology built for long-term industrial performance.
