Dock Lift with Hydraulic Lip – Heavy-Duty Loading Solution for All-Weather Conditions

Dock Lift with Hydraulic Lip – Heavy-Duty Loading Solution for All-Weather Conditions

A powerful, all-weather dock lift engineered to handle demanding loading operations with maximum safety and efficiency.

Ond Lift Germany supplied a Dock Lift with a hydraulic-operated lip designed for industrial loading zones that require reliable height compensation between ground level, vehicles, and loading docks.
Built for heavy loads and harsh environments, this dock lift ensures seamless goods transfer even under extreme temperatures.

⚙️ Project Overview

Product: Dock Lift with Hydraulic Lip
Capacity: 4,000 kg
Platform Size: 2300 × 2000 mm
Closed Height: 340 mm
Stroke: 1,250 mm
Lip Type: Hydraulic lip on the short side
Electrical System: IP65
Hydraulic Oil: Suitable for temperatures down to –30°C
Safety Features:

• 1 fixed handrail (short side)
• 1 fixed handrail (long side)

🏭 Project Requirements

The customer required a robust, temperature-resistant dock lift to support loading and unloading operations in an industrial logistics environment. Key needs included:

• Handling 4-ton loads safely and repeatedly
• Ensuring smooth height bridging using a hydraulically operated dock lip
• Reliable performance in cold storage or outdoor areas with freezing temperatures
• A large and stable platform to accommodate pallet trucks, trolleys, or forklifts
• A corrosion-resistant, sealed electrical system
• Fixed handrails for enhanced operator safety

Durability, reliability, and safety in all-weather conditions were essential.

💡 Ond Lift Germany’s Engineered Solution

Ond Lift Germany provided a heavy-duty dock lift system tailor-made for cold environments and intensive logistics use:

Hydraulic Lip for Efficient Loading

• Located on the short side
• Automatically bridges the gap to trucks, docks, or platforms
• Ensures stable and safe load transfer during every cycle

High-Performance Lift Mechanism

• 1,250 mm stroke allows flexible height compensation for a wide variety of vehicles
• 340 mm closed height enables easy ground-level loading
• Reinforced design ensures long-term stability under full load

Built for Extreme Temperatures

• Hydraulic oil rated for –30°C, ensuring smooth and consistent movement
• Ideal for cold warehouses, exterior docks, and refrigerated logistics zones

IP65 Electrical System

• Protected from dust and water ingress
• Suitable for wet, outdoor, or washdown environments

Safety-Optimized Construction

• Fixed handrail on the short side
• Fixed handrail on the long side
• Ensures operator protection while loading or unloading

This dock lift ensures reliable, fast, and safe material transfer in demanding logistics processes.

⚙️ Technical Specifications

🔩 Project Outcome

The installed dock lift provides:

• Safe and efficient loading operations thanks to the hydraulic lip
• Reliable functionality in sub-zero temperatures, perfect for cold-storage or outdoor docks
• Improved logistics flow through fast and stable height adjustment
• High operator safety with fixed handrails and IP65 protected components
• Long-term durability, even under intensive and heavy-duty usage

The dock lift now forms a crucial element in the customer’s loading infrastructure, ensuring efficient and secure material handling year-round.

OND Lift Germany – Advanced Dock Handling Solutions for Tough Industrial Environments.
